Model | PPYL type 9 layers |
Vehicle dimensions | 5300mm×1900×1550 (specifically adjusted according to the actual size on site) |
Vehicle quality | ≤2350kg |
Rated speed | Lifting speed 60m/min Trolley travel speed 90m/min Trolley walking speed 45m/min |
Motor power | Lifting motor 22kw Trolley motor 2.2kw Trolley travel motor 0.75kw |
Drive mode | Motor chain |
Operation mode | Key, card swipe |
Power requirements | Three-phase five-wire 380V/50HZ |
Safety device | Anti-falling, anti-vehicle, emergency stop and nearly 20 other types |
