Garage type | Vertical lift and lower type |
Vehicle dimensions | 5300mm×1900×1550 (specifically adjusted according to the actual size on site) |
Vehicle quality | ≤2350kg |
In and out type | Enter the warehouse; exit the warehouse. |
Transportation type | Comb tooth exchange |
Speed | Elevating speed 90m/min Lateral speed 12 m/min Rotating speed 3.5r/min |
Motor | Upgrade motor 30-37kw Slider motor 0.2kw Synchronous motor 1.5kw |
Control mode | Central control room for centralized control, PLC for automatic control. |
Operation mode | Read card auto/Touch screen auto/Manual |
Monitoring system | Closed-circuit television system |
Power supply requirements | AC380V 50HZ three-phase five-wire system dual power supply, automatic switching to the garage main control cabinet |
